Mishimoto MMRAD-MIA-99 is a direct-fit performance aluminium radiator for Mazda MX-5 MK2 / NB and MK2.5 / NB-FL 1.6 and 1.8 models with manual transmission, designed to provide increased cooling capacity over the original radiator.
Constructed entirely from aluminium, the Mishimoto radiator replaces the original plastic-and-aluminium style unit with a two-row brazed aluminium core and TIG-welded aluminium end tanks. The increased core thickness provides greater coolant volume and heat-transfer area for road, modified and track-focused MX-5 applications.
Mishimoto publishes an increase of up to 30% in cooling efficiency compared with a standard radiator for this specific product. This is a manufacturer-published performance figure and actual cooling performance will depend on the vehicle, cooling system and operating conditions.
The radiator has been designed around the original Mazda mounting arrangement, allowing installation without cutting or permanent modification. It is supplied with a Mishimoto 1.3 bar high-pressure radiator cap and magnetic drain plug.
Product Specifications
- Brand: Mishimoto
- Part Number: MMRAD-MIA-99
- Product Type: Performance aluminium radiator
- Application: Mazda MX-5 MK2 / NB & MK2.5 / NB-FL
- Engines: 1.6 & 1.8 litre
- Transmission: Manual transmission
- Construction: Full aluminium
- Core Construction: Brazed aluminium
- End Tanks: TIG-welded aluminium
- Rows: 2
- Core Thickness: 2.05" / approximately 52 mm
- Core Dimensions: approximately 22.17" x 12.8" / 563 x 325 mm
- Overall Dimensions: approximately 26.2" x 17.2" x 2.55" / 665 x 437 x 65 mm
- Inlet Diameter: 1.25" / approximately 32 mm
- Outlet Diameter: 1.25" / approximately 32 mm
- Drain Plug Thread: M16
- Published Coolant Capacity: 1.79 US gal / approximately 6.78 litres
- Radiator Cap: Mishimoto 1.3 bar high-pressure cap included
What's Included?
- 1x Mishimoto performance aluminium radiator
- 1x Mishimoto 1.3 bar radiator cap
- 1x Mishimoto magnetic drain plug
Fitment
Suitable for Mazda MX-5 MK2 / NB and MK2.5 / NB-FL 1.6 and 1.8 manual-transmission models. Mishimoto specifies this radiator for manual-transmission vehicles; automatic-transmission applications require separate transmission-oil cooling provision.
The radiator is designed as a direct-fit replacement using the original vehicle mounting arrangement. The cooling system must be drained before installation and correctly refilled and bled afterwards. This is also a suitable time to inspect the radiator hoses, clamps, thermostat and coolant condition.
Why Mishimoto?
Mishimoto specialises in performance cooling and thermal-management components. Its vehicle-specific aluminium radiators combine increased core capacity with all-aluminium construction and are designed around the original vehicle installation, making them particularly suited to MX-5s where improved cooling capacity is required for demanding road or track use.
| Model | Generation (Mk) | Sub-variant | Year Range | Engine | Transmission |
|---|---|---|---|---|---|
| Mazda MX-5 | MK2 / NB | NB | 1998-2002 | 1.6 | Manual |
| Mazda MX-5 | MK2 / NB | NB | 1998-2002 | 1.8 | Manual |
| Mazda MX-5 | MK2.5 / NB-FL | NB-FL | 2002-2005 | 1.6 | Manual |
| Mazda MX-5 | MK2.5 / NB-FL | NB-FL | 2002-2005 | 1.8 VVT | Manual |
Transmission restriction: Manual-transmission models. Automatic applications require separate transmission-oil cooling provision.
| Manufacturer | OE / Reference Number |
|---|---|
| Mazda | BP4W-15-200A |
| Mazda | BP4W-15-200 |
